Lenovo Legion 5 16IRX9 (83DG004JUS)- Intel Core i9-14900HX, 24C – 32GB DDR5-5600(2x 16GB) – 1TB SSD M.2 2280 NVMe – RTX 4060 8GB GDDR6 – 16″ WQXGA (2560×1600) IPS 350nits , 100% sRGB, 165Hz – Win 11- Luna Grey -1Year

Description

Lenovo Legion 5 16IRX9 – Gaming Laptop

Model: Legion 5 16IRX9
Part Number: 83DG004JUS
Brand: Lenovo

---

Performance

Processor:
Intel® Core™ i9-14900HX
24 Cores (8P + 16E) / 32 Threads
P-core: 2.2GHz up to 5.8GHz
E-core: 1.6GHz up to 4.1GHz
36MB Cache

AI PC Category: AI-Powered Gaming PC

Graphics:
NVIDIA® GeForce RTX™ 4060
8GB GDDR6
Boost Clock: 2370MHz
TGP: 140W
AI Performance: 233 AI TOPS

Chipset: Intel® HM770

Special Features: Dedicated AI Chip (LA1)

---

Memory & Storage

Installed Memory:
32GB DDR5-5600 (2× 16GB SO-DIMM)

Memory Slots:
2× DDR5 SO-DIMM (Dual Channel)

Maximum Memory:
Up to 64GB DDR5-5600

Storage:
1TB M.2 2280 NVMe™ PCIe® 4.0 x4 SSD

Storage Slots:
2× M.2 PCIe® 4.0 x4

Storage Support:

• M.2 2242 SSD up to 1TB

• M.2 2280 SSD up to 1TB

Card Reader: microSD Card Reader
Optical Drive: None

---

Display

Size: 16″ IPS
Resolution: WQXGA (2560 × 1600)
Refresh Rate: 165Hz
Brightness: 350 nits
Color Gamut: 100% sRGB
Surface: Anti-glare

Display Features:
Dolby Vision® • NVIDIA® G-SYNC® • Low Blue Light

Touchscreen: No
Color Calibration: Factory Color Calibrated

---

Audio & Camera

Audio Chip: Realtek® ALC3287 HD Audio
Speakers: Stereo 2W ×2, Nahimic Audio optimized
Camera: Full HD 1080p with Electronic Privacy Shutter
Microphones: Dual-array

---

Keyboard & Touchpad

Keyboard: 4-Zone RGB Backlit, English (US)
Touchpad: Precision TouchPad (PTP), Mylar® surface
Touchpad Size: 75 × 120 mm

---

Design & Build

Color: Luna Grey

Material:
Aluminium (Top) / PC-ABS (Bottom)

Surface Treatment:
Aluminium Stamping (Anodized with Sandblasting)

Dimensions:
359.7 × 262.3 × 19.7–25.2 mm

Weight: Around 2.36 kg

---

Battery & Power

Battery: Integrated 80Wh
Power Adapter: 230W Slim Tip (3-pin)

---

Connectivity

Wi-Fi: Wi-Fi® 6E (802.11ax 2×2)
Bluetooth: Bluetooth® 5.2
Ethernet: Gigabit RJ-45 (100/1000M)
WWAN: Not Supported

---

Ports

• 2× USB-A (USB 3.2 Gen 1 / 5Gbps)

• 1× USB-A (USB 3.2 Gen 1 / 5Gbps, Always On)

• 1× USB-C® (USB 3.2 Gen 2 / 10Gbps, Lenovo® PD 140W, DisplayPort™ 1.4)

• 1× USB-C® (USB 3.2 Gen 2 / 10Gbps, DisplayPort™ 1.4)

• 1× HDMI® 2.1 (up to 8K @ 60Hz)

• 1× Headphone / Microphone Combo (3.5mm)

• 1× Ethernet (RJ-45)

• 1× microSD Card Reader

• 1× Power Connector

---

Software

Operating System: Windows® 11 Home (English)
Bundled Software: Microsoft Office Trial

---

Security & Privacy

Security Chip: Firmware TPM 2.0
Camera Privacy: Electronic Shutter (E-shutter)
Fingerprint Reader: No

---

Warranty & Service

Base Warranty: 1-Year Courier / Carry-in
Bundled Accessories: None
